短路帽

                                         http://www.yznkdz.com/ 揚州諾凱電子有限公司

                        SHORTING AND OPEN CAPS

 短路與開路帽

       YANGZHOU NUOKAI ELECTRonICS CO LTD (NK) offers durable weather proof shorting and open caps. Common uses include designating fixtures for maintenance, keeping lights continually on for safety (shorting cap), or disconnecting service when lighting is no longer needed (open cap). 107& 109 caps provide a convenient and economical method to close or open the primary circuit with a NEMA locking type receptacle. The 107 model also incorporates a 545 Joule metal Oxide Varistor (MOV) that protects the cap and the luminaire from transient line surges. Designating ANSI housing comply with NEMA/ ANSI C136.10 specification. This unique housing makes it easier for users to distinguish visually between a standard photo‐control and a shorting or open cap.

           揚州諾凱電子有限公司為客戶提供耐用的耐風雨的短路與開路接線解決方案，提供包括燈具維護、維修在內的便利性– 短路帽（107系列）的安裝能使得電路保持持續的安全通電的狀態，當需要切斷時，可采用109系列開路帽產品使其線路得以切斷。產品設計采用了NEMA標準規定的旋鈕式自鎖插座配套用的插片端子結構，為接通和切斷臨時的電路提供了便捷與經濟性的解決方案。SC‐107‐04‐BL‐SP545 的設計加入了氧化鋅壓敏電阻浪涌保護器件，從而能夠在短路帽與燈具遭受瞬態浪涌時為其提供浪涌保護。產品外殼的設計符合NEMA /ANSI C136.10 規范要求。獨特的外殼設計為用戶區分光控器產品與短路帽或開路帽提供了可視化的顏色區分。

        NK SC系列短路/開路帽為安裝有NEMA旋鈕式插座的光控設備的前端電路導通或切斷提供   了一種便捷而低廉的解決方案.

      聚碳酸酯（PC）抗紫外線罩殼

      高強度抗沖擊丁二醇酯（PBT）基座

      符合UL773/ANSI C136.10標準

      產品有UL&CUL認證
