適用于各種主流品牌汽車儀表，專用儀表步進電電機。
具有高準確度，抗震動能力強等特點。適用與東風小康、五菱、別克凱越、福田、BYD、江淮等各種品牌。
最大速度: 600°/sec
High speed rotation: 600°/sec
最小步進角度:1/12°
High micro-step resolution:1/12°
工作電壓:3.5-10V
Wide working voltage:3.5-10V
低能耗
Low current consumption
電機尺寸:Φ30mm x 7.5 mm
Small dimension:Φ30mm x 7.5 mm
|
Electrical and Mechanical Characteristics電氣與機械特性 |
||||||
|
Parameter |
Test Condition |
Min. |
Typ. |
Max. |
Unit |
|
|
Operating Temperature |
工作溫度 |
Temperature溫度: 25℃±3℃ |
-40 |
- |
105 |
℃ |
|
Resistance |
線圈電阻 |
260 |
280 |
300 |
Ω |
|
|
Operating Current |
驅動峰值電流 |
- |
15 |
20 |
mA |
|
|
Start-Stop Frequency |
啟停頻率 |
*JL=2.0X10-7kgm2 |
- |
- |
200 |
0/sec |
|
Max.Driving Speed |
最高速度 |
- |
- |
600 |
0/sec |
|
|
|
|
|
|
|
|
|
|
Gear Ratio |
齒數比 |
|
- |
1:180 |
- |
- |
|
Full Step Size |
全步角度 |
- |
1 |
- |
Degree |
|
|
Parital Step Size |
分步角度 |
- |
1/3 |
- |
Degree |
|
|
Micro Step Size |
微步角度 |
- |
1/12 |
- |
Degree |
|
|
Motor Inertia at Output |
馬達慣量 |
- |
- |
4.36E-7 |
kgm2 |
|
|
Backlash |
齒隙回程差 |
- |
0.7 |
1.0 |
Degree |
|
|
Rotational Angle |
轉動角度 |
- |
330 |
- |
Degree |
|
|
Noise |
噪音 |
@200 °/s |
- |
39 |
- |
dB(A) |
|
@400 °/s |
- |
43 |
- |
dB(A) |
||
|
|
|
|
|
|
|
|
|
Holding Torque @ 5V |
保持扭力(5V) |
|
3.5 |
4.0 |
- |
mNm |
|
Acceleration of sinus vibration test |
振動測試 |
Pointer inertia load 0.2XE-6 kgm2 |
- |
- |
6 |
g |
|
Axial Force - Push On |
軸向壓力 |
Test Method |
- |
100 |
120 |
N |
|
Axial Force - Pull Off |
軸向拉力 |
- |
70 |
80 |
N |
|
|
Perpendicular Force |
橫向力 |
- |
- |
12 |
N |
|
|
Stoper External Torque |
擋點保持力 |
- |
- |
80 |
mNm |
|
|
Soldering Temp. |
焊接溫度 |
Max. 5 sec. |
- |
- |
290 |
℃ |
