技術參數 Technical specifications
|
【型號/Model:DJZX20】 |
控制電壓 Control voltage |
AC 220V (可選/ as agreed) |
|
|
適用于操作ISO標準20’集裝箱 For operation with ISO standard 20’ container |
總功率 Total power |
<1KW |
|
|
額定起重量 Rated lifting load |
41T |
防護等級 Precaution class |
IP 55 |
|
允許載荷偏心 Allowable load eccentricity |
±10% |
導板類型 Flippers Model |
固定導板 Fixed Flipper |
|
四角吊耳負重 Load of lifting lugs at four corner |
12.5t×4 |
環境溫度 Ambient temperature |
-20℃~+55℃ |
|
自重(吊具部分) Self-weight (spreader) |
3.5t |
轉銷形式 Twist lock Mode |
ISO浮動轉銷,電機驅動 ISO floating twist lock, driven by an motor |
|
轉銷( 90°) Twist lock rotation 90° |
~ 1 S |
適用 Application |
岸橋,軌道吊,輪胎吊,門座式起重機 QC, RMG, RTG, Portal crane |
|
電源電壓/頻率 Power voltage/ Frequency |
AC 380V (3P)/50HZ (可選/ as agreed) |
||
