用途：

該機適用于該機適用于牛皮紙，銅版紙等各種卷筒狀原紙的復卷分切作業理想設備。

USES:

This machine is suitable for this machine is suitable for kraft paper, coated paper and other reel of base paper rewinding cutting operation ideal equipment.

主要技術參數：

1.適用原料寬度：1800mm（根據客戶需求）

2.原料放卷最大直徑：φ1200mmφ3”φ6”

3.原料收卷最大直徑：?jiǎn)问?/span>φ1000mm  收卷軸φ3”φ6”

4.放卷張力：400N.M X2磁粉剎車

5.收卷電機功率：22KW（皖南變頻矢量電機，匯川變頻器）

6.吹廢邊電機：1.1KW

7.機械速度：350米/分，工作速度300米/分

8.圓刀分切系統

9.機架為50mm鋼板

10.主控制部分：隨機連體式

11.設備尺寸：38504300X2500

The main technical parameters:

1. The range of the material width: 1800 mm (according to customer requirements)

2. Rolling diameter Material: 1200 mmφ3” orφ6”

3. Raw material winding diameter: single closed scroll phi phi 1200 mm 3" 6”

4. Rolling tension: 400 n. M X2Magnetic powder brake

5. Winding motor power: 22 kw (frequency vector motor in the south of anhui, inovance inverter)

6. Blow the waste motor: 1.1 KW

7. The mechanical speed: 350 m/min, 300 m/min in her work

8. Circular knife cutting system

9. The chassis of 50 mm steel plate

10. The main control part: random postures

11. The equipment size: (length X width X height) 38504300X2500
